Product Specifications
| Durability | MIL-STD-810H certified- 4ft, 26 drops (each side, edge, and corner)- IP65 compliant- ±8kV contact discharge, ±15kV air discharge |
| Operating System | Windows 11 ProOptional: Windows 11 Home/IoT |
| Processor | Intel i5-1235U (12MB cache, up to 4.4 GHz, 10 cores, 12 threads, TDP 15W)- Optional: Intel i7-1255U (12MB cache, up to 4.7 GHz, 10 cores, 12 threads, TDP 15W) |
| Graphics | Intel® Iris® Xe Graphics eligible |
| Memory | 16GB LPDDR4x on board |
| Storage | 128GB SATA SSDOptional: 256GB SSD/512GB/1TB PCIe SSD |
| Display | 10.1", FHD (1200×1920), 700 nits- 10-point capacitive touch screen, supports GP930 active pen |
| Audio | Integrated microphone- Integrated 1W speaker- Class K |
| Camera | MF 2.0 MP front camera- AF 8.0 MP rear camera |
| Keyboard & Input | User-definable key (default SCAN key) ×1-WINDOWS key ×1,Volume up key ×1,Volume down key ×1,POWER key ×1 |
| Network & Connectivity | Intel® Wi-Fi 6 (802.11 ax)- Bluetooth® 5.1- 4G LTE- LTE-FDD: B1/3/5/7/8/20/28- LTE-TDD: B38/40/41- WCDMA: B1/5/8- GSM: /- Optional 5G- GPS/Glonass module- Optional: GPS/Beidou/Glonass module |
| Security | Integrated TPM2.0- Fingerprint scanner- Optional HF-RFID (NFC) reader |
| Data Capture | Optional 1D/2D barcode reader |
| I/O Interface | Micro SD card ×1- SIM card ×1- USB 3.1 (Type-A) ×1- USB 3.0 (Type-C) ×1- 3.5 mm audio jack ×1- HDMI 2.1a mini ×1- 5.5 mm DC In jack ×1- 12-pin Pogo Pin ×1 (Charge & USB) |
| Choose 1 from 4 | Default 10/100/1000M Ethernet (RJ45) ×1- Serial port (RS232: D-sub, 9-pin) ×1- USB 2.0 (Type-A) ×1, 1D/2D barcode reader |
| Battery & Charging | AC adapter: 100~240V, 50Hz~60Hz, 64.98W (19V/3.42A)- Li-ion battery, 7.4V, 5000mAh, 4.5h- Li-ion battery, 7.4V, 8600mAh- Separate RTC 3V/210mAh |
| Environment | Operating temperature: -20°C to 60°C (-4°F to 140°F)- Storage temperature: -30°C to 70°C (-22°F to 158°F)- Humidity: 95% (non-condensing) |
| Dimension | 289.9 mm (L) × 196.7 mm (W) × 21.2 mm (H) |
| Weight | 1230g |
| Accessories | Standard: Adapter, Cable AC, Hand strap, Carry handle- Optional: Docking charger, Vehicle mount, Removable battery, Quad charging dock |
| Warranty | One-year limited warranty standard |
Power Adapter
USB Cable
Shoulder Strap
Installed on the back of the main unit, it enables a comfortable grip, enhances stability during handling, and prevents the device from slipping out of your hand.
Battery
